Features:
1.Gluing part adopts special relocation mechanism, ensure the gluing nozzle will touch IG unit closely, but will not break it. And it can adapt to a certain range of displacement error or IG unit.
2.Sealing width is adjustable by inputting parameter, convenient and accurate. Sealing depth can be detected automatically. The sealing speed is controlled by sealing depth and gluing quantity, ensures the sealing quality. Adding glue on the IG unit corner, ensures the sealing quality at the corner.
3.All important electric elements, adopt imported famous brands, such as servo motor, controller, low-voltage apparatus, sensors, fiber optic photo switches an so on, which will make sure the equipment runs well, reliable and long service life.
4.Hydraulic glue, through pressure on the hydraulic station to meet the quantitative oil supply of the driving oil cylinder, so as to control the white glue for quantitative glue. And ensure the black glue quantitative glue through the mechanical linkage adjustment ratio. It is easy to use, simple and reliable.
5.The machine adopts the combination transfer mode of synchronous belt and an unique V block, smooth transmission, accurate positioning, less glue leakage, IG unit edge clean.
6.Automatic digital control system by servo motor ensures the equipment precision and glue precision. The system also has a unilateral sealing, alarming, dangerous to be automatic determination and lock function.
Parameter | |
Power supply | 380V 50HZ or customer specification |
Sealing speed | 3-35 m/min |
Sealing depth | <18mm |
IG thickness | 12 – 50 mm |
Min. IG unit size | 350 x 200 mm |
Max. IG unit size | 3000 x 2000 mm |
Glue supply pressure | <30Mpa |
Standard height | 400mm |
Angle of inclination | 6 degree |
Air pressure | 0.6 – 0.8 Mpa |
Total power | 11.3 Kw |
Max IG unit weight | 400 kgs |
Machine weight | 6410 kgs |
Contour dimension | 10000*3500*2700mm |
Main accessory | |
• Servo drive | Delta |
• Servo Motor | Delta |
• Solenoid valve | Airtac |
• Cylinder | Airtac |
• Air Filter Device | Airtac |
• Electrical Button and Switcher | Delixi |
• AC Contactor and Circuit Breaker | Delixi |
• Approach Switcher | Delixi |
